Weight of 10 Inch Drain Pipe Ductil Iron Pipe K7 K9 Ductil Iron Pipe Ductile Iron Pipe DN300 Caliber

Get high-quality DN300 caliber K7 K9 K7 10 Inch Ductile Iron Pipe from our factory. We manufacture durable and reliable drainage pipe solutions.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Certification
ISO2531, EN545, EN598, ISO4179, ISO8179
Shape
Round
Customized
Customized
Gasket Material
NR
Product Name
C40 Ductile Iron Pipe
Color
Black
Product Joint Type
T-Type Joint Pipe (Push-on)
Surface Treatment
Anti-Corrosion Coated
Test
100% Water Pressure Test
Internal Coating
Mortar Cement Lining
Joint Structure
Restrained Groove
Transport
Bulk Vessel
Item Name
ISO2531 Ductile Cast Iron Pipes
Specification
0.15-120mm
Trademark
hongtai
Origin
China Shandong
Production Capacity
20000/Ton

Product Description

Weight of 10 Inch Drain Pipe Ductil Iron Pipe K7 K9 Ductil Iron Pipe Ductile Iron Pipe DN300 Caliber
Weight of 10 Inch Drain Pipe Ductil Iron Pipe K7 K9 Ductil Iron Pipe Ductile Iron Pipe DN300 Caliber

Weight of 10 Inch Drain Pipe Ductil Iron Pipe K7 K9 Ductil Iron Pipe Ductile Iron Pipe DN300 Caliber
Weight of 10 Inch Drain Pipe Ductil Iron Pipe K7 K9 Ductil Iron Pipe Ductile Iron Pipe DN300 Caliber
Product Description
Hot-sale Corrosion Resistance Ductile Iron Pipe Factory Price
We supply pipes for potable water and sewerage applications in diameter range DN100mm-DN1000mm, all our pipes are manufactured in accordance with the latest version of BS EN545 for potable water and BS EN598 for sewerage.
Product Display
Weight of 10 Inch Drain Pipe Ductil Iron Pipe K7 K9 Ductil Iron Pipe Ductile Iron Pipe DN300 Caliber
Weight of 10 Inch Drain Pipe Ductil Iron Pipe K7 K9 Ductil Iron Pipe Ductile Iron Pipe DN300 Caliber



Product Name

Ductile cast iron pipe

Diameter

DN80mm-DN1600mm

Length

6000mm

Yield (≥Mpa)

270

Hardness

230HB

Pull Strength

420Mpa

Grade

K7, K8, K9, K10

Material

Ductile iron

Joint Structure

Push-on joint/mechanic joint

Certification

ISO2531/EN545/EN598/BV/WARS/SGS

Internal coating

Mortar cement lining/high alumina cement mortar lining

External coating

Zinc + bitumen painting+ epoxy painting

Color

Black bitumen/red epoxy

Quality Control

100% inspection + professional Lab test

Application

Sewage water/dringking water

Package

Packed by steel strips or as customized

Processing Service

Lining and spraying

Supply Ability

1000 tons per month ductile cast iron pipe


Classification

Based on joints

STD joint

T-type push-on joint

Binding joint

Based on internal and external coatings

Common coating

The internal coating of surface cement mortar

The internal coating of aluminate cement mortar

Zinc-aluminum coating

The internal coating of epoxy ceramic

Epoxy resin seal coating

Polyurethane coating

Weight of 10 Inch Drain Pipe Ductil Iron Pipe K7 K9 Ductil Iron Pipe Ductile Iron Pipe DN300 Caliber

Product Performance:
1.The performance of internal pressure resistance:
Centrifugal ductile iron has the essence of iron and the performance of steel, so the ductile iron pipes have excellent security performance than pipes made from other materials. The designed working pressure is much higher than that of pipes made from other materials, the safty factor is pretty high, and the possible burst pressure is three times of the working pressure.

2.The performance of outer pressure resistance:
The high pressure resistance can avoid the requirement of the pipe bed and protective cover, making the pipes laying rellable and economic.

3.Inner anti-corrosion layer:
The inner layer of ductile iron pipes are centrifugally sprayed with cement mortar. Cement lining complies with the international standard ISO4179, ensuring the mortar strong and smooth. The motor coating will not fall off or foul, and its thickness is even ensuring the drinking water transferred by the pipes get good protection.

4.Protective coating:
The zinc spraying of ductile iron pipes could protect the pipes proactively through the electrochemical effect of zinc and iron. With the high chiorinated resin paint, the pipes will get enhanced anti-corrosion protection. The surface zinc spraying of each pipe is not less than 130g/m², amd cpmplies with ISO8179 standard. We can also increase the zinc spraying thickness or spray zinc & aluminum alloy layer according to the customers' demand.
Weight of 10 Inch Drain Pipe Ductil Iron Pipe K7 K9 Ductil Iron Pipe Ductile Iron Pipe DN300 Caliber
Packing&Shipping
Weight of 10 Inch Drain Pipe Ductil Iron Pipe K7 K9 Ductil Iron Pipe Ductile Iron Pipe DN300 Caliber
Weight of 10 Inch Drain Pipe Ductil Iron Pipe K7 K9 Ductil Iron Pipe Ductile Iron Pipe DN300 Caliber
Company Profile
Weight of 10 Inch Drain Pipe Ductil Iron Pipe K7 K9 Ductil Iron Pipe Ductile Iron Pipe DN300 Caliber
Weight of 10 Inch Drain Pipe Ductil Iron Pipe K7 K9 Ductil Iron Pipe Ductile Iron Pipe DN300 Caliber
Weight of 10 Inch Drain Pipe Ductil Iron Pipe K7 K9 Ductil Iron Pipe Ductile Iron Pipe DN300 Caliber
Certificate
Weight of 10 Inch Drain Pipe Ductil Iron Pipe K7 K9 Ductil Iron Pipe Ductile Iron Pipe DN300 Caliber
