Basic Info.
Model NO.
EL-AP
Thickness
1mm-80mm
Length
1-12m
Delivery Time
15-30 Days After Down Payment
Alloy or Not
Alloy
Secondary or Not
Non Secondary
Standard or Not
Standard
Price Term
Fob,CIF,CNF
Payment
L/C,T/T
Transport Package
in Bundle or Wooden Case Can Discuss
Specification
6mm-760mm
Trademark
Kingmetal
Origin
China (Mainland)
HS Code
73045110
Production Capacity
10000 Ton/Tons / Month
Product Description
Standard: ASTM SA213, SA335, A369, A209, A250; JIS G3462, JIS G3467,
DIN17175, BS3059-2, GB/T8162, GB/T6479, GB/T9948, GB5310, etc.
Material:
GB/T: Cr5Mo, 15CrMo, 12Cr1MoV P11/22 T91, P91, P9, T9, Wb36, 42CrMo4/4140/SCM 440
ASTM: A-335/A199 Gr. P1 /P5 /P9 / P11 /P12 / P22 / P91, A213T5, T11, T12, T22, P5, P9, P22, P9(SEAMLESS)
A691- 1 1/4CR, 2 1/4CR, 5CR, 9CR etc(WELDED)
DIN: 15Mo3 / 13CrMo44 / 10CrMo910(SEAMLESS)
JIS: STPA12/STPA25/STPA22/STPA24( SEAMLESS)
Application: Petroleum, chemical industry, electric power, boiler, high temperature resistant,
low temperature resistant, corrosion resistant alloy pipe used.
Mechanical properties
DIN17175, BS3059-2, GB/T8162, GB/T6479, GB/T9948, GB5310, etc.
Material:
GB/T: Cr5Mo, 15CrMo, 12Cr1MoV P11/22 T91, P91, P9, T9, Wb36, 42CrMo4/4140/SCM 440
ASTM: A-335/A199 Gr. P1 /P5 /P9 / P11 /P12 / P22 / P91, A213T5, T11, T12, T22, P5, P9, P22, P9(SEAMLESS)
A691- 1 1/4CR, 2 1/4CR, 5CR, 9CR etc(WELDED)
DIN: 15Mo3 / 13CrMo44 / 10CrMo910(SEAMLESS)
JIS: STPA12/STPA25/STPA22/STPA24( SEAMLESS)
Application: Petroleum, chemical industry, electric power, boiler, high temperature resistant,
low temperature resistant, corrosion resistant alloy pipe used.
| Grade | C | Si | Mn | P | S | Cr | Mo |
P5 | Max.0.15 | Max.0.50 | 0.3-0.6 | Max.0.025 | Max.0.025 | 4-6 | 0.45-0.65 |
P11 | 0.05-0.15 | 0.5-1.0 | 0.3-0.6 | Max.0.025 | Max.0.025 | 1.0-1.5 | 0.44-0.65 |
P12 | 0.05-0.15 | Max.0.50 | 0.3-0.61 | Max.0.025 | Max.0.025 | 0.8-1.25 | 0.44-0.65 |
P22 | 0.05-0.15 | Max.0.50 | 0.3-0.6 | Max.0.025 | Max.0.025 | 1.9-2.6 | 0.87-1.13 |
Mechanical properties
Grade | Yield point (Mpa) | Tensile strength (Mpa) | Elongation(%) | Impact value(J) |
P5 | ≥205 | ≥415 | See table | ≥35 |
P11 | ≥205 | ≥415 | See table | ≥35 |
P12 | ≥220 | ≥415 | See table | ≥35 |
P22 | ≥205 | ≥415 | See table | ≥35 |
