28 Inch Large Diameter Gcr15simn 52100 100crmn6 1.3502 Seamless Steel Tube Hot Finished Seamless Carbon Alloy Steel Pipe Gcr15

Shop our 28 inch large diameter seamless steel tube made from Gcr15simn 52100 100crmn6 1.3502 alloy. Hot finished for superior performance. As a factory, we provide high-quality seamless carbon alloy steel pipes.
Request a Quote

PRODUCTS DETAILS

  • Overview
  • Product Description
  • Chemical Composition (%)
  • Heat Treatment
  • Product specification
  • product application
  • Packaging & Shipping
  • FAQ
Overview

Basic Info.

Model NO.
28 inch large diameter GCr15SiMn 52100 100CrMn6 1.
Invoicing
by Actual Weight
Thickness
4mm-150mm
Length
12m
Tolerance
±5%, ±1%
Oiled or Non-Oiled
Non-Oiled
Delivery Time
7-20 Days
Product Name
Seamless Alloy Steel Tube/Pipe
Transport Package
Customized or Regular Shipping According to Custom
Specification
OD 4-2420MM
Trademark
MEIDE
Origin
Shandong, China
HS Code
7304319000
Production Capacity
200000 Ton/Tons Per Month

Product Description

28 Inch Large Diameter Gcr15simn 52100 100crmn6 1.3502 Seamless Steel Tube Hot Finished Seamless Carbon Alloy Steel Pipe Gcr15
Product Description
Alloy Steel 52100, as known as AISI 52100, contains a high level of carbon and chromium. This alloy offers users good machinability, as well as forming through conventional methods. The hardening of Alloy Steel 52100 can be achieved by cold working, heating, and quenching.
28 Inch Large Diameter Gcr15simn 52100 100crmn6 1.3502 Seamless Steel Tube Hot Finished Seamless Carbon Alloy Steel Pipe Gcr15
Chemical Composition (%)
Grades C Si Mn P S Cr Mo Cu Ni
GCr15/52100 0.95-1.05 0.15-0.35 0.2-0.4 ≤0.027 ≤0.02 1.3-1.65 ≤0.1 ≤0.25 ≤0.3
GCr15SiMn 0.95-1.05 0.45-0.75 0.95-1.25 ≤0.025 ≤0.025 1.4-1.65 ≤0.1 ≤0.25 ≤0.3
100Cr6 0.95-1.05 0.15-0.35 0.25-0.45 ≤0.025 ≤0.025 1.4-1.65 ≤0.08 ≤0.25 ≤0.3
440C 0.9-1.0 0.80 0.80 ≤0.035 ≤0.030 16-18 ≤0.75 ≤0.25 ≤0.60
100CrMn6 1.05 0.75 1.25 0.025 0.025 1.65 0.1 0.25 0.3
Heat Treatment
Quenching
Tempering
Heating Temperature/ºC
Cooling
Hardness/HRC
Heating Temperature/ºC
Cooling
Hardness/HRC
830-850
Oil
62-65
150-190
Air
58-62

Heat Treatment for ASTM 52100 Bearing Steel.

ASTM/AISI 52100 alloy bearing steel is heated at 816°C followed by quenching in oil. Before performing this process, it is
subjected to normalizing heat treatment at 872°C followed by slowly cooling in order to reduce the machining stress.
Hot Working
AISI 52100 bearing steels alloy can be hot worked at 205 to 538°C.
Cold Working
AISI 52100 bearing steel can be cold worked using conventional techniques in the annealed or normalized conditions.
Annealing
For spheroidize anneale, the following isothermal anneal is recommended:
* 1500ºF (815ºC) for 3 hours
* 1350ºF (735ºC) for 4 hours
* 1250ºF (675ºC) for 3 hours
* Slow cool to 1000ºF (540ºC) then air cool.
Quenching
AISI 52100 alloy bearing steel could be hardened by quenching in water from 801-829 degree or quench in oil from 816-842 degree.
Tempering
Temper to desired hardness as indicated by tempering curves after water or oil quench.
28 Inch Large Diameter Gcr15simn 52100 100crmn6 1.3502 Seamless Steel Tube Hot Finished Seamless Carbon Alloy Steel Pipe Gcr15
28 Inch Large Diameter Gcr15simn 52100 100crmn6 1.3502 Seamless Steel Tube Hot Finished Seamless Carbon Alloy Steel Pipe Gcr15 28 Inch Large Diameter Gcr15simn 52100 100crmn6 1.3502 Seamless Steel Tube Hot Finished Seamless Carbon Alloy Steel Pipe Gcr15
Product specification
Tolerances
Pipe types Pipe sizes(mm) Tolerances


Hot rolled
OD<50 ±0.50mm
OD≥50 ±1%
WT<4 ±12.5%
WT 4~20 +15%, -12.5%
WT>20 ±12.5%




Cold drawn
OD 6~10 ±0.20mm
OD 10~30 ±0.40mm
OD 30~50 ±0.45
OD>50 ±1%
WT≤1 ±0.15mm
WT 1~3 +15%, -10%
WT >3 +12.5%, -10%
28 Inch Large Diameter Gcr15simn 52100 100crmn6 1.3502 Seamless Steel Tube Hot Finished Seamless Carbon Alloy Steel Pipe Gcr15
product application

52100 Alloy Seamless Tube & Pipe For Bearing

1. For making all kinds of bearing ring and rolling element, such as steel ball roller and ferrule of inernal combustion engine, electric motorcycle, automonilrd tractors, machine tools, rolling mill, boring machine, mining machinery, general machinery, high load and high speed roating mechanical transmission bearing.
2. Sometimes also used to make tools, such as pumching die and measuring tools.
3. The automotive and aircraft industry use Alloy Steel 52100 for a number of different applications including.
4. Anti-friction bearings
5. Mill rolls
6. Taps
7. Punches
8. Aircraft parts
28 Inch Large Diameter Gcr15simn 52100 100crmn6 1.3502 Seamless Steel Tube Hot Finished Seamless Carbon Alloy Steel Pipe Gcr15
Packaging & Shipping

1. Bundle and pack.
2. Warning for inclined end or flat end or according to buyer's requirements.
3. Marking: According to customer requirements.
4. Apply varnish.
5. Plastic covers at both ends.

28 Inch Large Diameter Gcr15simn 52100 100crmn6 1.3502 Seamless Steel Tube Hot Finished Seamless Carbon Alloy Steel Pipe Gcr15
28 Inch Large Diameter Gcr15simn 52100 100crmn6 1.3502 Seamless Steel Tube Hot Finished Seamless Carbon Alloy Steel Pipe Gcr15 28 Inch Large Diameter Gcr15simn 52100 100crmn6 1.3502 Seamless Steel Tube Hot Finished Seamless Carbon Alloy Steel Pipe Gcr15
FAQ

Q1:who are we?
A:We are based in Shandong, China, start from 2022,sell to North America(60.00%),Western Europe(14.00%),South America(6.00%).
There are total about 11-50 people in our office.

Q2. how can we guarantee quality?
A:Always a pre-production sample before mass production;
Always final Inspection before shipment;

Q3.what can you buy from us?Which ports are accepted for delivery?
A:Copper,Aluminum,Mould steel, Seamless carbon steel,Precision steel pipe,The steel plate,Alloy steel,Titanium,Custom machine parts.It can be delivered from Qingdao, Tianjin, Shanghai, Guangzhou and other ports.


Q4.why should you buy from us not from other suppliers?
A:Shandong Meide Import and Export Co., Ltd. has 25 years of production experience. With advanced precision production equipment
and modern large warehouses, has a stockpile of 200,000 tons of goods, has a number of long-term stable cooperative customers.

Q5.what services can we provide?
A:Accepted Delivery Terms: FOB,CFR,CIF,EXW;
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,PayPal;
Language Spoken:English,Chinese

Q6.Can we get the some samples?Any charges?
A:Yes,you can get available samples in our stock.Free for real samples,but customers need to pay the freight cost.

Q7.How can we get your price ?
A:We need below information to quote for you:
1). Product Name
2). Standard
3). Material Grade (Chemical Composition)
4). Dimension
5). Quantity
6). The Drawing for Special Parts
