Basic Info.
Model NO.
Seamless Pipe API 5L Grade B 1020 X42~X70
Length
3000-12000mm, or as Per Request
Heat Treatment
Annealed/Normalized/Q+T
Payment Term
30% Tt Deposit, Balance Against Bl Copy
Grain Size
ASTM E112
Non-Metallic Inclusiton
ASTM E45
Certificate
ISO, ABS, BV, CCS, Dnv, Lr, Gl, Mill Certificate
Quality Inspection
NDT, Chemical Composition, Physical Properties/SGS
Experience
15 Years Manufacturer Experience
Seamlee Pipe-Line Pipe
API 5L Grade B, X42, X46, X52, X56, X60, X65, X70
Seamlee Pipe-OCTG
API 5CT Casing&Tubing, (K55/J55/L80/N80/P110)
Seamless Pipe 3
Structural and Mechanical Tube(St37/44/55/52)
Seamlee Pipe 4
Fluid Pipe, ASTM A53m/A106, Grade a/B
Seamlee Pipe 5
Boiler Tube, DIN17175, GB5310, GB3087
Welded Steel Pipe-ERW/LSAW/SSAW
API 5L Grade B, X42, X46, X52, X56, X60, X65, X70
Pipe Accessories
Pipe Fittings, Flanges, Vavels
Transport Package
Seaworthy Package
Specification
dia 10-2500mm
Trademark
Qilu
Origin
China
HS Code
722840
Production Capacity
500, 000tons/Year
Product Description
Hot Rolled Prime Mild Carbon Steel Seamless Pipe API 5L Grade B 1020 X42~X70
1: 1020 steel introduction
AISI 1020 steel is a low hardenability and low tensile carbon steel which has a nominal 0.22%C and 0.55%Mn. It has excellent weldability,good machinability ,and high ductility with Brinell hardness of 119 - 235 and tensile strength of 410-790 MPa. It is normally used in turned and polished or cold drawn condition. Due to its low carbon content, it is resistant to induction hardening or flame hardening. Due to lack of alloying elements, it will not respond to nitriding. However, carburization is possible in order to obtain case hardness more than Rc65 for smaller sections that reduces with an increase in section size. Core strength will remain as it has been supplied for all the sections. Alternatively, carbon nitriding can be performed, offering certain benefits over standard carburizing.
.
2: 1020 Steel equivalent
3: 1045 steel chemical composition
4: 1020 steel mechanical properties
The mechanical properties mainly include tensile strength, yield strength, elongation, area or reduction, hardness, impact value, non-metalic inclusion etc. Different heat treatment, the mechanical properties will be different, such as normalized, tempered, QT. If you want to know the properties, kindly contact us
5: 1020 steel overviews
6: Delivery condition
For hot forged bar, usually the delivery condition is hot forged, annealed/QT, rough turned/Black surface.
For hot rolled bar, usually the delivery condition is hot rolled, annealed/QT, Black surface.
For Cold Drawn bar, usually the delivery condtion is cold drawn, annealed/QT, peeled/black surface
For hot rolled plate, usually the delivery condition is hot rolled, annealed, milled/black surface
For hot forged plate, usually the delivery condition is hot forged, normalized/annealed, milled/black surface.
Hunan Qilu Industrial Co., Ltd has the capacity to forge round steel, steel flat, square steel, module, shaft and roller, etc. The main specifications of the products include Φ80-1000mm forging materials and 80-1200mm square billets and which the maximum piece weight can reach 50T.
Hunan Qilu Industrial Co., Ltd were already engaged in exporting steel for 11 years, could supply a great variety of hot forged, hot rolled and cold drawn Steels, including engineering steel, cold work tool steel, hot work tool steel, plastic mold steel, spring steel, high speed steel, stainless steel etc., besides Qilu Industrial also has their own heating treatment shop and machining shop to provide heating and cutting service.
Since 2008 year, Hunan Qilu Industrial has the right to export all FORGED STEEL behalf of Qilu Speical Steel Co.,ltd which is specialized in smelting and forging of special steel since 1965 year, now Qilu special steel is one of the biggest manufacturer of forged product in China.The forged products are used in Automotive, Aerospace, Power Generation, Oil & Gas, Transportation and Industrial. We already set up the warehouse in Wuxi and Dongguan city, more than 20000 tons ex-stock could be supplied with kinds of size.
Qilu Industrial is the professional one-stop steel manufacturer, stockist and exporter in China, our customers spread all over the world, include West Europe, North America, South America, Asia, Middle Asia, Africa, Australia, etc.
The company owns advanced special steel smelting facilities and forging processing equipments, the main steel-making equipment include 2 sets of 50t ultra-high power electric arc furnaces,2 sets of 60t LF refining furnaces,1 set of 60t vacuum degassing refining furnace and 4 sets of 1-20t electroslag re-melting furnaces.
The main forging equipments mainly include:3 sets of 5t electro-hydraulic hammers, 1 set of high-speed forging units of 800t,1600t,2000t and 4500t respectively.
Hunan Qilu Industrial CO., LTD
Web: qilusteel.en.made-in-china.com
1: 1020 steel introduction
AISI 1020 steel is a low hardenability and low tensile carbon steel which has a nominal 0.22%C and 0.55%Mn. It has excellent weldability,good machinability ,and high ductility with Brinell hardness of 119 - 235 and tensile strength of 410-790 MPa. It is normally used in turned and polished or cold drawn condition. Due to its low carbon content, it is resistant to induction hardening or flame hardening. Due to lack of alloying elements, it will not respond to nitriding. However, carburization is possible in order to obtain case hardness more than Rc65 for smaller sections that reduces with an increase in section size. Core strength will remain as it has been supplied for all the sections. Alternatively, carbon nitriding can be performed, offering certain benefits over standard carburizing.
.
2: 1020 Steel equivalent
| Country | Japan | British | Germany | USA |
| Standard | JIS G4051 | EN / BS | EN 10083-2 | ASTM A20 |
| Grade | S20C | EN3B /070M20 | C20/1.1151 | 1020 |
3: 1045 steel chemical composition
| Grade | C | Si | Mn | P | S |
| 1020 | 0.17-0.23 | ≤ 0.4 | 0.30-0.60 | ≤ 0.04 | ≤ 0.05 |
4: 1020 steel mechanical properties
The mechanical properties mainly include tensile strength, yield strength, elongation, area or reduction, hardness, impact value, non-metalic inclusion etc. Different heat treatment, the mechanical properties will be different, such as normalized, tempered, QT. If you want to know the properties, kindly contact us
| Diameter mm | Tensile Strength Mpa | Yield Strength Mpa | Elongation % | Reduction of area % | Condition |
| ≤ 16 | 500 - 650 | ≥ 340 | ≥20 | ≥50 | Quenched and tempered |
| >16 - 40 | 470 - 620 | ≥290 | ≥22 | ≥50 | |
| ≤ 16 | ≥430 | ≥240 | ≥24 | Normalised | |
| >16 - 100 | ≥410 | ≥3210 | ≥25 |
5: 1020 steel overviews
| Size | Round | Dia 10-2500mm |
| Plate/Flat/Block | Thickness 6mm-500mm | |
| Width 20mm-1000mm | ||
| Heat treatment | Normalized ; Annealed ; Quenched ; Tempered | |
| Surface condition | Black; Peeled; Polished; Machined; Grinded; Turned; Milled | |
| Delivery condition | Forged; Hot rolled; Cold drawn | |
| Test | Tensile strength, Yield strength, elongation, area of reduction, impact value, hardness, grain size, ultrasonic test, US inspection, magnetic particle testing, etc. | |
| Payment terms | T/T;L/C;/Money gram/ Paypal | |
| Trade terms | FOB; CIF; C&F; etc.. | |
| Delivery time | 30-45 days | |
| Application | AISI 1020 steel can be largely utilized in all industrial sectors in order to enhance weldability or machinability properties. It is used in a variety of applications due to its cold drawn or turned and polished finish property.It is used for simple structural application such as cold headed bolts,and also used in the case hardened condition. | |
6: Delivery condition
For hot forged bar, usually the delivery condition is hot forged, annealed/QT, rough turned/Black surface.
For hot rolled bar, usually the delivery condition is hot rolled, annealed/QT, Black surface.
For Cold Drawn bar, usually the delivery condtion is cold drawn, annealed/QT, peeled/black surface
For hot rolled plate, usually the delivery condition is hot rolled, annealed, milled/black surface
For hot forged plate, usually the delivery condition is hot forged, normalized/annealed, milled/black surface.
Hunan Qilu Industrial Co., Ltd has the capacity to forge round steel, steel flat, square steel, module, shaft and roller, etc. The main specifications of the products include Φ80-1000mm forging materials and 80-1200mm square billets and which the maximum piece weight can reach 50T.
Hunan Qilu Industrial Co., Ltd were already engaged in exporting steel for 11 years, could supply a great variety of hot forged, hot rolled and cold drawn Steels, including engineering steel, cold work tool steel, hot work tool steel, plastic mold steel, spring steel, high speed steel, stainless steel etc., besides Qilu Industrial also has their own heating treatment shop and machining shop to provide heating and cutting service.
Since 2008 year, Hunan Qilu Industrial has the right to export all FORGED STEEL behalf of Qilu Speical Steel Co.,ltd which is specialized in smelting and forging of special steel since 1965 year, now Qilu special steel is one of the biggest manufacturer of forged product in China.The forged products are used in Automotive, Aerospace, Power Generation, Oil & Gas, Transportation and Industrial. We already set up the warehouse in Wuxi and Dongguan city, more than 20000 tons ex-stock could be supplied with kinds of size.
Qilu Industrial is the professional one-stop steel manufacturer, stockist and exporter in China, our customers spread all over the world, include West Europe, North America, South America, Asia, Middle Asia, Africa, Australia, etc.
The company owns advanced special steel smelting facilities and forging processing equipments, the main steel-making equipment include 2 sets of 50t ultra-high power electric arc furnaces,2 sets of 60t LF refining furnaces,1 set of 60t vacuum degassing refining furnace and 4 sets of 1-20t electroslag re-melting furnaces.
The main forging equipments mainly include:3 sets of 5t electro-hydraulic hammers, 1 set of high-speed forging units of 800t,1600t,2000t and 4500t respectively.
