Basic Info.
Model NO.
SCH10/SCH40/SCH80 SMLS
Usage
Pipeline Transport, Boiler Pipe, Hydraulic/Automobile Pipe, Oil/Gas Drilling, Food/Beverage/Dairy Products, Machinery Industry, Chemical Industry, Mining, Construction & Decoration
Section Shape
Round
Alloy or Not
Alloy
Oiled or Non-Oiled
Slight Oiled
Tolerance
+/-1%
Weight
by Theoretical Weight
Length
3m,5.8m,6m,11.8m,12m or as Per Your Request
Certificate
ISO,Mtc
Price Term
EXW/Fca/Fob/CFR/CIF
Payment Term
T/T or L/C
Inspection
SGS/BV/TUV
Package
in Bundle with The Steel Strip and End Cap
Transport
by Container, Bulk Ship, Railway
Stock
10000ton
Delivery Time
Within 7 Days Upon Receipt of Deposit
Quality
Top Quality Guaranteed
Supply Capacity
400000ton/Year
Transport Package
Standard Export Package
Specification
SA192 SA106 P9 P11 P22 P91 ASTM A213 Etc.
Trademark
Chicago Steel
Origin
China
HS Code
73045110
Production Capacity
400000ton
Product Description
Fast Delivery SCH80 Alloy Steel Boiler Tube High Pressure Heat Exchanger Tubing Thin Wall A179 Carbon Steel Seamless Pipe Austenitic Stainless Steel Tube/Pipe
Steel Boiler Pipe is a type of seamless steel pipe that is specifically designed to withstand high pressure and temperatures in boiler and heat exchanger applications. It is made from high-quality carbon steel or alloy steel and is often used in power plants, refineries, and other industrial settings. Steel Boiler Pipe is available in various grades and sizes, and can be customized to meet the specific needs of different applications. With its superior strength, durability, and resistance to corrosion, Steel Boiler Pipe is a reliable and cost-effective solution for demanding industrial environments.
ASTM A213 seamless pipes tubes Standard Specification for Seamless Ferritic and Austenitic Alloy-Steel Boiler, Superheater, and Heat-Exchanger Tubes This specification covers seamless ferritic and austenitic steel boiler, superheater, and heat-exchanger tubes. Grades containing the letter H in their designation have requirements different from those of similar grades not containing the letter H. These different requirements provide higher creep-rupture strength than normally achievable in similar grades without these different requirements. The tubes shall be made by the seamless process and shall be either hot finished or cold finished, as specified. Grade TP347HFG shall be cold finished. Heat treatment shall be done separately and in addition to heating for hot forming. The ferritic alloy and ferritic stainless steels shall be reheated. On the other hand, austenitic stainless steel tubes shall be furnished in the heat-treated condition. Alternatively, immediately after hot forming, while the temperature of the tubes is not less than the minimum solution temperature, tubes may be individually quenched in water or rapidly cooled by other means. Tension test, hardness test, flattening test, and flaring test shall be done to each tube. Also, each tube shall be subjected to the nondestructive electric test or hydrostatic test.
ASTM A192 / A192M is the standard applicable to seamless carbon steel boiler tubes for high-pressure service
ASTM A192 seamless steel tube sizes and thicknesses usually furnished to this specification are 1⁄2 in. to 7 in. [12.7 to 177.8 mm] outside diameter and 0.085 to 1.000 in. [2.2 to 25.4 mm], inclusive, in minimum wall thickness. Tubing having other dimensions may be furnished, provided such tubes comply with all other requirements of this specification.
ASTM A192 seamless steel tubes mechanical property requirements do not apply to tubing smaller than 1⁄8 in. [3.2 mm] inside diameter or 0.015 in. [0.4 mm] thickness.
| Product Name | High Pressure boiler tube Galvanized Seamless Steel Tube for Boiler steam pipe |
| Material | Mo Steel, Cr-Mo Steel, Cr- Mo-W Steel |
| industry | Baosteel |
| Standard | ASME SA-106, ASME SA-192M. ASME SA-209M. ASME SA-210M.ASTM A 106M. ASTE A192M.EN 10216-2. DIN 17175, JIS G 3456. JIS G 3461. JIS G 3462 |
| Grade | SA-106B, SA-192. SA-210A1, SA-106C, SA-210C. SA-209T1. SA-213 T11. |
| Uses | For manufacture wall panel, economizer, reheater,superheater and steam pipeline of boilers |
| Steel Grade: | 106B,210A1,210C,P9,P11,T1,T11,T2,T5,T12,T22,T23,T91,T92,P235GH,13CrMo4-5,15Mo3,10CrMo9-10, ST35.8,ST45.8,STB340,STBA 12-2,API5L,5CT 304,304L,309S,310S,316,316L,317,317L,321,347,347H,304N,316L, 316N,201,202,S32205,S31803 |
| Standard: | ASME/ASTM SA/A53/513/106/209/210/213/335/178/179/519 ASME/ASTM SA/A213,A312,A269,A778,A789, DIN 17456, DIN17457,DIN 17459,DIN17175,EN10216,BS3605,BS3059 JIS G3458,JISG3459,JIS G3461,JIS G3462,JIS G3463 |
| Specification: | Outdiameter 10~508mm |
| Wt: | 1.0-30mm,or according to customer's special request |
| Length: | 2-20meters,or according to customer's special request |
| Package: | Export Standard Package |
| Typies of tube: | Boiler tube,precision tube,mechanical tubing,cylinder tube,line pipes,etc |
| Mill MTC: | Supplied before shipment |
| Inspection: | The Third Party inspection can be accepted,SGS,BV,TUV |
| Mount port: | Any port in China |
| Trade Term: | FOB,CIF,CFR,EXW,etc. |
| Price Term: | TT or LC at sight |
| Our services: | We can customized according to customer's requriement or drawing ,packaging according to customers' request |
| ASTM A179/(ASME SA179) | |
| Seamless Cold Drawn Low Carbon Steel Heat Exchanger And Conderser Tubes | |
| Application: | For tubular heat exchangers,condensers,and similar heat transfer apparatus. |
| Size(mm): | O.D.:6.0~114.0 W.T.:1~15 L:max 12000 |
Grade and Chemical Composition (%)
| Chemical Composition | C | Mn | P≤ | S≤ | Si≤ |
| 0.06-0.18 | 0.27-0.63 | 0.035 | 0.035 | 0.25 |
Tolerance(SA-450/SA-450M):
| OD In (mm) | + | - | WT In(mm) | + | - |
| <1(25.4) | 0.10 | 0.10 | ≤1.1/2(38.1) | 20% | 0 |
| 1~1.1/2(25.4~38.1) | 0.15 | 0.15 | >1.1/2(38.1) | 22% | 0 |
| >1.1/2~<2(38.1~50.8) | 0.20 | 0.20 | |||
| 2~<2.1/2(50.8~63.5) | 0.25 | 0.25 | |||
| 2.1/2~<3(63.5~76.2) | 0.30 | 0.30 | |||
| 3~4(76.2~101.6) | 0.38 | 0.38 | |||
| >4~7.1/2(101.6~190.5) | 0.38 | 0.64 | |||
| >7.1/2~9(190.5~228.6) | 0.38 | 1.14 |
ASTM A192/A192M-02 | |
| Seamless Carbon Steel Bolier Tubes for High-Pressure | |
| Application: | For seamless carbon steel bolier and superheater tubes for high-pressure service |
| Size(mm): | O.D.:6.0~114.0 W.T.:1~15 L:max 12000 |
Grade and Chemical Composition (%)
| Chemical Composition | C | Mn | P≤ | S≤ | Si≤ |
| 0.06-0.18 | 0.27-0.63 | 0.035 | 0.035 | 0.25 |
Tolerance(SA-450/SA-450M):
| OD In (mm) | + | - | WT In(mm) | + | - |
| <1(25.4) | 0.10 | 0.10 | ≤1.1/2(38.1) | 20% | 0 |
| 1~1.1/2(25.4~38.1) | 0.15 | 0.15 | >1.1/2(38.1) | 22% | 0 |
| >1.1/2~<2(38.1~50.8) | 0.20 | 0.20 | |||
| 2~<2.1/2(50.8~63.5) | 0.25 | 0.25 | |||
| 2.1/2~<3(63.5~76.2) | 0.30 | 0.30 | |||
| 3~4(76.2~101.6) | 0.38 | 0.38 | |||
| >4~7.1/2(101.6~190.5) | 0.38 | 0.64 | |||
| >7.1/2~9(190.5~228.6) | 0.38 | 1.14 |
2) Shipping: We have long-term cooperation with many experienced shipping companies and will find the most suitable mode of transportation for you.
3) Trade terms: FOB/CIF/CFR/EXW
4) Shipping port: Tianjin/Qingdao
5) Shipment: A: Length: ≤6m, loaded in 20GP Container. B: Length: ≤12m, loaded in 40GP Container.
Remark: Size of 20GP Container (inside :5898*2352*2393mm); Size of 40GP Container (inside:12032*2352*2393mm); Size of 40HQ Container (inside:12032*2352*2698mm).
6) Delivery time: Normal size: 7-15days send from warehouse directly. Special size:15-25days.
Adequate inventory, Good quality, Strict testing, Quick delivery, High -quality service!
Any demand for the steel pipe and boiler tube, welcome to inquiry us online!
