Basic Info.
Product Description
Cold-drawn precision seamless steel pipe is a kind of high precision steel pipe material. The main categories are: precision seamless steel pipe, precision hydraulic seamless steel pipe, cold-drawn precision seamless steel pipe, cold-rolled precision seamless steel pipe, high precision seamless steel pipe, precision bright seamless steel pipe. | Product Name | Precision steel pipe/Hot rolled seamless carbon tube/alloy steel pipe/steel tube |
| Standard | ASTM A106 ,ASTM A53 ,API5L B ,ASTM A179, ASTM A210 ,ANSI B36.10, GB 5310,GB6479,GB9948,GB/T17396GB 3087, GB/T 8162 ,GB/T8163 |
| Outer Diameter | 10.3-914mm |
| Wall Thickness | 4-150mm |
| Length | 6m,12m or as per customer's requirements |
| Packing | In bundles tied with steel stripes |
| Payment Term | T/T, L/C at sight |
| Delivery Time | Within 7-60 days after signing the contract or as your requirement |
| Delivery condition | Beveled or Plain end with varnish/2PP/2PE/3PE/3PP anticorrosive coatingas per clients confirmation ; With or without protecting caps as percustomer's requirements;with FBE internal coating for water steel pipes. |
| Material | A53(A,B),A106(A,B),Q345,16Mn, 10# 20#,45# S235JR, 1010,1020,1030,1040,1050,ASTMA252 Gr.2,Gr.3; ST37,ST42,ST52;Gr.B,X42,X46,X52,X56,X60,X65,X70, etc |
| Usage | for petroleum/ natural gas pipeline , for conveying water,drainage,coal gas, mineral slurry and other low-middle pressure liquids. Also for chemical industry, building structure,heat-supply and pile driving projects. |
| Export to | Canada, USA, Argentina,Peru, Chile, Colombia, Brazil, Venezuela,Malaysia, Singapore, the Czech Republic, Australia, Myanmar, Kenya, South Africa, Spain, Italy, France, England, the Netherlands,Belgium, etc |
| Certificates | API 5L; ISO9001:2000 |
| Material | C | Si | Mn | P | S | Cr | Ni | Cu | Mo |
| ASTM 4119 GB 12CrMo | 0.08-0.15 | 0.17-0.37 | 0.4-0.7 | 0.035 | 0.035 | 0.4-0.7 | 0.3 | 0.3 | 0.4-0.55 |
| JIS SCM415 GB 15CrMo | 0.12-0.18 | 0.17-0.37 | 0.4-0.7 | 0.035 | 0.035 | 0.8-1.1 | 0.3 | 0.3 | 0.4-0.55 |
| ASTM 4118 GB 20CrMo | 0.17-0.24 | 0.17-0.37 | 0.4-0.7 | 0.035 | 0.035 | 0.8-1.1 | 0.3 | 0.3 | 0.15-0.25 |
| ASTM 4130 GB 30CrMo | 0.26-0.34 | 0.17-0.37 | 0.4-0.7 | 0.035 | 0.035 | 0.8-1.1 | 0.3 | 0.3 | 0.15-0.25 |
| ASTM 4135 GB 35CrMo | 0.32-0.4 | 0.17-0.37 | 0.4-0.7 | 0.035 | 0.035 | 0.8-1.1 | 0.3 | 0.3 | 0.15-0.25 |
| ASTM 4140 GB 42CrMo | 0.38-0.45 | 0.17-0.37 | 0.5-0.8 | 0.035 | 0.035 | 0.9-1.2 | 0.3 | 0.3 | 0.15-0.25 |
| ASTM 4142 GB 42CrMnMo | 0.4-0.45 | 0.15-0.35 | 0.78-1 | 0.035 | 0.04 | 0.8-1.1 | 0.25 | 0.35 | 0.15-0.25 |
| Material | Diameter of sample d mm | Heat treatment or condition. | Tensile strength σb Mpa | Point of yield σs Mpa | Ratio of elongation δ % | Reduction of section ψ % | hardness HBW | Shock absorption energy KV2 J |
| ASTM 4119 GB 12CrMo | d=30 | Quenching + tempering | ≥410 | ≥265 | ≥24 | ≥60 | ≤179 | ≥110 |
| JIS SCM415 GB 15CrMo | d=30 | Quenching + tempering | ≥440 | ≥295 | ≥22 | ≥60 | ≤179 | ≥94 |
| ASTM 4118 GB 20CrMo | d=15 | Quenching + tempering | ≥885 | ≥685 | ≥12 | ≥50 | ≤197 | ≥78 |
| ASTM 4130 GB 30CrMo | d=25 | Quenching + tempering | ≥930 | ≥785 | ≥12 | ≥50 | ≤229 | ≥63 |
| ASTM 4135 GB 35CrMo | d=25 | Quenching + tempering | ≥980 | ≥835 | ≥12 | ≥45 | ≤229 | ≥63 |
| ASTM 4140 GB 42CrMo | d=25 | Quenching + tempering | ≥1080 | ≥930 | ≥12 | ≥45 | ≤217 | ≥63 |
Specification: outer diameter of hot-rolled pipe is 32~630mm. The wall thickness is 2.5~75mm. The outer diameter of cold rolled (cold drawn) pipe is 5~200mm. The wall thickness is 2.5~12mm.
Appearance quality: the internal and external surfaces of steel pipes shall be free of cracks, folds, folds, delamination, hairlines and scabs. These defects shall be completely removed, and the wall thickness and outer diameter shall not exceed the negative deviation after removal.
Both ends of the steel pipe shall be cut at right angles and the burrs shall be removed. Gas cutting and hot saw cutting are allowed for steel pipes with wall thickness greater than 20mm. The head may not be cut after the agreement between the supplier and the supplier.
Seamless pipes are widely used. Seamless pipes for general purposes are rolled by ordinary carbon structural steel, low alloy structural steel or alloy structural steel, with the largest output, and are mainly used as pipes or structural parts for conveying fluid.
Supply is divided into three types according to different purposes: a. Supply according to chemical composition and mechanical properties; B. Supply according to mechanical properties; C. Supply according to hydraulic test. The steel pipes supplied according to category a and b shall also be subjected to hydraulic test if they are used to bear liquid pressure.
There are many kinds of seamless pipes for special purposes, such as boiler seamless pipes, geological seamless pipes and petroleum seamless pipes.
Q1:who are we?
A:We are based in Shandong, China, start from 2022,sell to North America(60.00%),Western Europe(14.00%),South America(6.00%).There are total about 11-50 people in our office.
Q2. how can we guarantee quality?
A:Always a pre-production sample before mass production;
Always final Inspection before shipment;
Q3.what can you buy from us?Which ports are accepted for delivery?
A:Copper,Aluminum,Mould steel, Seamless carbon steel,Precision steel pipe,The steel plate,Alloy steel,Titanium,Custom machine parts.It can be delivered from Qingdao, Tianjin, Shanghai, Guangzhou and other ports.
Q4.why should you buy from us not from other suppliers?
A:Shandong Meide Import and Export Co., Ltd. has 25 years of production experience. With advanced precision production equipment
and modern large warehouses, has a stockpile of 200,000 tons of goods, has a number of long-term stable cooperative customers.
Q5.what services can we provide?
A:Accepted Delivery Terms: FOB,CFR,CIF,EXW;
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,PayPal;
Language Spoken:English,Chinese
Q6.Can we get the some samples?Any charges?
A:Yes,you can get available samples in our stock.Free for real samples,but customers need to pay the freight cost.
Q7.How can we get your price ?
A:We need below information to quote for you:
1). Product Name
2). Standard
3). Material Grade (Chemical Composition)
4). Dimension
5). Quantity
6). The Drawing for Special Parts
