Basic Info.
Product Description
ASTM A179/A179M-90a (Reapproved 2001)
Cold drawn seamless low-carbon steel heat exchanger and condenser steel pipes
Scope of application: 1. This standard is applicable to the thinnest seamless steel pipes used in tubular heat exchangers, condensers, and similar heat transfer devices;
2. This standard is applicable to steel pipes ranging from 3.2 to 76.2mm.
General requirements: Unless otherwise specified in this standard, it shall also comply with the applicable clauses of ASTM A450/A450M.
Surface quality: No oxide scale, other surface quality shall comply with ASTM A450/A450M regulations.
Brand and chemical composition (%) C Mn P S
0.06-0.18 0.27-0.63 ≤ 0.035 ≤ 0.035
Note: It is not allowed to provide alloy grades that specifically require the addition of elements other than those mentioned above.
Heat treatment: After the final cold drawing, perform heat treatment at a temperature not lower than 650 ºC.
Hardness test: HRB ≤ 72, sampling requirement is to take any two steel pipes from each batch for Rockwell hardness test. The so-called batch refers to all steel pipes with the same nominal diameter and wall thickness produced from the same furnace without cutting. If it is a batch furnace, the batch only refers to steel pipes with the same furnace number, size, and heat treatment in the same furnace;
Product name | Seamless Steel Pipe / Seamless Steel Tube |
Standard | AiSi ASTM GB JIS DIN |
Grade | API A106 GR.B A53 Gr.B AP175-79,ASTM A500,ASTM A179/A192/A213/A210 /370 WP91, WP11,WP22 API5L X42-X65 X80 T11 T91 P91,DIN2I5L,DIN17440, DIN2448,JIS G3452-54,20G 12Cr1movg 15Crmo 42Crmo,20#,45# Q345R S235JR S275JR S355JR,Q195,Q235A-B,Q345A-E, 20#, 10#,16Mn,SS400,St37,St52,S355TRH 160Mn,27SiMn,40Cr,Cr5Mo,12Cr1MoV,12Cr1MovG,15CrMo,15CrMoG,15CrMoV, 13CrMo44,T91,27SiMn,25CrMo,30CrMo,35CrMo,35CrMoV, 40CrMo,45CrMo,Cr9Mo,10CrMo910,15Mo3,A335P11,P22,P91,T91,102,ST45.8-111,A106B |
Length | 5.8m 6m Fixed, 12m Fixed, 2-12m Random |
Place of Origin | China |
Brand Name | BAO STEEL AN STEEL TPCO TISCO etc. |
Outside Diameter | 1/4'--50' |
6mm-1500mm | |
Technique | 1/2'--6': hot piercing processing technique |
6'--24' : hot extrusion processing technique | |
Usage /Application | Oil pipe line, Drill pipe, Hydraulic pipe, Gas pipe, Fluid pipe, Boiler pipe,Conduit pipe, Scaffolding pipe pharmaceutical and ship building etc. |
Tolerance | ±1% |
Processing Service | Bending, Welding, Decoiling, Cutting, Punching |
Alloy Or Not | Is Alloy |
Delivery Time | 8-14 days |
Material | API5L,Gr.A&B, X42, X46, X52, X56, X60, X65, X70, X80, ASTM A53Gr.A&B,ASTM A106 Gr.A&B, ASTM A135, ASTM A252, ASTM A500, DIN1626, ISO559, ISO3183.1/2, KS4602, GB/T911.1/2,SY/T5037, SY/T5040 STP410,STP42 |
End | Bevel end(>2"), Plain (≤2"),with plastic cap, with screwed and socket |
Surface | Black Painted, Galvanized, Natural, Anticorrosive 3PE coated,polyurethane foam Insulation |
Packing | Standard Sea-worthy Packing |
Delivery Term | CFR CIF FOB |
| C | Si | Mn | Mo | Cr | V |
12Cr1MoVG | 0.08~0.15 | 0.17~0.37 | 0.40~0.70 | 0.25~0.35 | 0.90~1.20 | 0.15~0.30 |
