Basic Info.
Model NO.
GPE
Surface Treatment
Spray-Paint
Operation Pressure
Atmospheric Pressure
Material
Alloy
Product Name
API 5dp Oilfield Drilling Rig Seamless G105 Nc26 2
Transport Package
Export Packing
Specification
K55 J55 N80 L80 P110
Trademark
GOLDENMAN
HS Code
8431
Production Capacity
150000
Packaging & Delivery
Package Size
250.00cm * 80.00cm * 80.00cm
Package Gross Weight
200.000kg
Product Description
API 5DP oilfield drilling rig seamless G105 NC26 2 3/8" drill pipe
API 5DP oilfield drilling rig seamless G105 NC26 2 3/8" drill pipe
drill pipe comply with the provisions under the Standards API SPEC 5DP and API SPEC7. The grade of steel for the drill pipe will
be determined according to the requirements of Group 1 and Group 3 of API SPEC 5DP.
(i.e.: Group 1--Grade E; Group 3--Grade X-95, Grade -G-105 and Grade -S-135)
As per requirements of customers, drill pipe joints at the same level will be provided, and manufactured drill pipe joints will
comply with the provisions under the Standard API SPEC 7.
Seamless G105 Drill Pipe
Nc50 API Drill Pipe
Welcome to consult, we will provide the most comprehensive technical support!
drill pipe comply with the provisions under the Standards API SPEC 5DP and API SPEC7. The grade of steel for the drill pipe will
be determined according to the requirements of Group 1 and Group 3 of API SPEC 5DP.
(i.e.: Group 1--Grade E; Group 3--Grade X-95, Grade -G-105 and Grade -S-135)
As per requirements of customers, drill pipe joints at the same level will be provided, and manufactured drill pipe joints will
comply with the provisions under the Standard API SPEC 7.
Seamless G105 Drill Pipe
Nc50 API Drill Pipe
Welcome to consult, we will provide the most comprehensive technical support!
| Size | Weight | Grade | Wall thickness | Upset types | ||
| Inch | mm | Inch | mm | |||
| 2 3/8 | 60.3 | 6.65 | E.X.G.S | 0.28 | 7.11 | EU |
| 2 7/8 | 73 | 10.4 | E.X.G.S | 0.362 | 9.19 | IU,EU |
| 3 1/2 | 88.9 | 9.5 | E | 0.254 | 6.45 | IU,EU |
| 3 1/2 | 88.9 | 13.3 | E.X.G.S | 0.368 | 9.35 | IU,EU |
| 3 1/2 | 88.9 | 15.5 | E | 0.449 | 11.4 | IU,EU |
| 3 1/2 | 88.9 | 15.5 | X.G.S | 0.449 | 11.4 | EU,IEU |
| 4 | 101.6 | 14 | E.X.G.S | 0.33 | 8.38 | IU,EU |
| 4 1/2 | 114.3 | 13.75 | E | 0.271 | 6.88 | IU,EU |
| 4 1/2 | 114.3 | 16 | E.X.G.S | 0.337 | 8.56 | EU,IEU |
| 4 1/2 | 114.3 | 20 | E.X.G.S | 0.43 | 10.92 | EU,IEU |
| 5 | 127 | 16.25 | X.G.S | 0.296 | 7.52 | EU |
| 5 | 127 | 19.5 | E | 0.362 | 9.19 | IEU |
| 5 | 127 | 19.5 | X.G.S | 0.362 | 9.19 | EU,IEU |
| 5 | 127 | 25.6 | E | 0.5 | 12.7 | IEU |
| 5 | 127 | 25.6 | X,G,S | 0.5 | 12.7 | EU,IEU |
