Basic Info.
Product Description
| Grade: | Container plate: A516Gr60, A516Gr70, Q345R,16MnR,Q370R, 16MnDR, 15CrMoR, A572Gr60,A573Gr70, 13MnNiMoR, 15CrMoR,12MnNiVR, 07MnNiMoR, 09MnNiDR,A537 CL1, A537CL2, A537CL3 |
| Low-alloy plate: Q345B/C/D/E, Q390A/B/C/D, Q420A/B/C | |
| High-strength plate: Q460C/D, JG590, Q550D, Q690D, SM490A-L | |
| Ship plate: A,B,D,E,AH32, AH36, DH32, DH36, EH32, EH36 | |
| Bridge steel: Q235QC, Q345QC, Q345QD, Q370QD, Q235GJD, Q345GJB, Q345GJC, Q345GJD,J510L, ZQS345QK, ZQS460QK | |
| Brand: | Wuyang mill, Shougang mill, Angang mill, Jigang mill, Baosteel etc. |
| Certification: | ISO, SGS, BV, CE or as required |
| Thickness: | 6mm-180mm |
| Width: | 1500mm, 1800mm, 2000mm, 2200mm, 2500mm,3000mm or as required. |
| Length: | 3000mm, 6000mm, 8000mm, 12000mm or as required. |
| Surface | Commonly mill finished surface,Bare,Galvanized,Coated etc. |
| Standard: | ASTM,JIS,EN,DIN,BS,GB,etc |
| Delivery time: | 7 days after confirming the order |
| MOQ: | 1 ton or 1 pc |
| Payment term: | L/C at sight or 30% T/T as deposit and the balance paid against copy of B/L |
| Applications: | Construction, building, outside wall, railway, containers etc. |
This specification covers the standard for heat-treated carbon manganese-silicon steel plates intended for fusion welded pressure vessels and structures. The steel shall be killed and undergo normalization, quenching and tempering. Heat and product analyses shall be performed on the materials and results shall conform to the required values in chemical composition in carbon, manganese, phosphorus, sulfur, silicon, copper, nickel, chromium and molybdenum. Mechanical testing like tension test shall be done on the plates and shall conform to the required tensile strength, yield strength, and elongation.
Plates furnished under this specification are available in the following three class:
Steel Grade:
A537 CL1, A537 CL2, A537 CL3
Mechnical property for A537 boiler steel:
| Thickness(mm) | Yield strength (≥Mpa) | Tensile strength (Mpa) | Elongation in ≥,% | ||
| 200mm | 50mm | ||||
| A537 CL1 | T≤65 | 345 | 485-620 | 18 | 22 |
| 65<T≤100 | 310 | 450-585 | 18 | 22 | |
| 100<T | 310 | 450-585 | 18 | 22 | |
| A537 CL2 | T≤65 | 415 | 550-690 | 20 | 22 |
| 65<T≤100 | 830 | 515-655 | 20 | 22 | |
| 100<T | 315 | 485-620 | 20 | 22 | |
| A537 CL3 | T≤65 | 380 | 550-690 | 20 | 22 |
| 65<T≤100 | 345 | 515-655 | 20 | 22 | |
| 100<T | 275 | 485-620 | 20 | 22 | |
Chemical composition for A537 boiler steel (Heat Analysis Max%)
| Thickness(mm) | C | Si | Mn | P | S | Cu | Ni | Cr | Mo | |
| A537 CL1 | T≤40 | ≤0.24 | 0.15-0.55 | 0.70-1.35 | ≤0.025 | ≤0.025 | ≤0.35 | ≤0.25 | ≤0.25 | ≤0.09 |
| T>40 | 1.00-1.60 | |||||||||
| A537 CL2 | T≤40 | ≤0.24 | 0.15-0.50 | 0.7-1.6 | ≤0.035 | ≤0.035 | - | ≤0.25 | ≤0.25 | ≤0.08 |
| A537 CL3 | T≤40 | ≤0.24 | 0.15-0.50 | 0.7-1.6 | ≤0.035 | ≤0.035 | ≤0.35 | ≤0.25 | ≤0.25 | ≤0.08 |
Packed with pallets,wooden cases woven bag,PVC or PE, and stel frame support on wood pallet or other seaworthy export packing in 20' or 40' containeror as per customers' requirements
The inner size of container is below:
20ft GP: 5.8m(length) x 2.3m(width) x 2.18m(high) about 24-26CBM,25MTS
40ft GP: 11.8m(length) x 2.3m(width) x 2.18m(high) about 54CBM,25MTS
40ft HQ: 11.8m(length) x 2.3m(width) x 2.72m(high) about 68CBM,27MTS
1. More than 10 years Professional steel export service. Have own production line.
2. Advanced CNC machine.
3. Low cost&Quick Delivery&High quality.
4. Integrity, strength and quality of products recognized by the industry.
5. Most of our clients are international, the domestic well-known enterprises.
6. Has a complete scientific quality management system.
7. Can meet any requirements for all kinds of sheet metal processing with advanced equipment.
Pre-sale Service:
1.Good quality + Factory price + Quick response + Reliable service
2.100% responsible for the quality:all the products are produced by our professional workman and we have a high-work-effect foreigh trade team.
3.We have enough stock and can deliver in short time.
4.Customized designs,colors,sizes and logos are welcome,responsiveness to customers' requirements.
After-sale Service:
1.We will count cheapest shipping cost and make invoice to you at once.
2.On time delivery.
3.Provide real pictures of loading container,email you the tracking NO. and help to chase the products until the goods arrive you.
4.24 hours online service,if any question,please contact us at anytime in your convenience.
1. Q: Are you a manufacturer?
A:Yes, we are manufacturers. We have our own factory and our own company. I believe we will be the most suitable supplier for you.
3. Q: Do you have quality control system?
4. Q: Can you arrange the shipment for us?
5. Q: How long is your delivery time?
6. Q: Can I get some samples?
7. Q: What is your after-sale service?
8. Q: What is your MOQ?
More questions, please send the email to us!
