Basic Info.
Model NO.
WAN761
Carbon Steel Pipe
Seamless, Welded
Size
1/2"~24"
Wt
Sch5s~Xxs
Prodduct Name
09cupcrni-a Steel Pipes
Keyword
09cupcrni-a Seamless Carbon Steel Pipe
Transport Package
Wooden Box, in Bundles or as Customer′s Request
Specification
1/2"~24"
Trademark
Kingmertal
Origin
China
HS Code
73060000
Production Capacity
50000tons/Year
Product Description
09CuPCrNi-A Steel Pipes manufacturer, 09CuPCrNi-Aseamless steel pipe,09CuPCrNi-ASteel Pipes exporter & 09CuPCrNi-A seamless Steel Pipes supplier in China,09CuPCrNi-A carbon steel pipe,...
Product description : 09CuPCrNi-A steel pipes ,09CuPCrNi-A carbon steel pipes ,Low alloy ND Steel Pipe Material 09CuPCrNi-A steel pipe .
09CuPCrNi-A seamless pipe ,09CuPCrNi-A seamless steel pipe manufacturer in China
1.Standard of 09CuPCrNi-A seamless Steel Pipes
GB4171-84 ( plate)
GB 150.2-2011
Purpose of 09CuPCrNi-A Steel Pipes
It is widely used in power plants and refineries to make the economizer, air preheater, heat exchanger and evaporator to
resist the corrosion of sulfur containing flue gas.
Grade | 09CuPCrNi-A Chemical Composition | |||||||
09CuPCrNi-A | C | Mn | P | S | Si | Cr | Cu | Ni |
0.12 | 0.20-0.50 | 0.07-0.15 | 0.040 | 0.25-0.75 | 0.30-1.25 | 0.25-0.55 | 0.12-0.65 |
More standard and material steel pipes besides 09CuPCrNi-A Steel Pipes we can supply is as following :
Standard | ASTM A213 ,A335,A519,EN10216-2,JIS G3458,G3462,G3467,GB5310,DIN17175 |
Out Diameter | 10-813mm |
Wall Thickness | 1-41mm |
Material | Cr5Mo (T5 P5 STFA 25 STPA25 STBA25) 15CrMo (T12 P12 STFA22 STPA22 STBA22) 1.25Cr0.5Mo (T11 P11 STFA23 STPA23 STBA23) Cr9Mo (T9 P9 STFA26 STPA26 STBA26) 12Cr2Mo (T22 P22 10CrMo910) 10Cr9Mo1VNb (T91 P91) 12Cr1MoV 12Cr2MoWVTiB (R102) |
Length | 1-12m or as customers required |
Surface treatment | Black painting, black varnish, transparent oil, epoxy coating, etc. |
Technique | Seamless |
Usage | 1. Low and middle pressure fluid transportation pipeline 2. Casing Tube 3. Boiler Pipe 4. Petroleum and natural gas industry 5. Chemistry industry 6. Electric industry |
Supply | 1. Seamless steel pipe 2. steel casing 3. tubing 4. hot-rolled steel pipe |
steel pipe, steel pipes, steel piping, seamless steel pipe
