Basic Info.
Usage
Pipeline Transport, Boiler Pipe, Hydraulic/Automobile Pipe, Oil/Gas Drilling, Food/Beverage/Dairy Products, Machinery Industry, Chemical Industry, Mining, Construction & Decoration, Special Purpose
Section Shape
Round
Size
Od Size:10-910mm Wall Thickness (W.T.):1mm-56mm
Length
6m or Customized as Request
Lapping Form
Full Scaffolding
Structural Style
Multi-Pole Scaffolding
Specificatione
48.3/48.6
Thickness
1.6-4.0mm
Transport Package
Standard Seaworthy Shipment Package
Specification
as required
Trademark
Chicago
Origin
China(Mainland)
HS Code
73063090
Production Capacity
50000t Per Month
Product Description
Scaffolding tubes, galvanized steel tubes, are metal sections of pipe used to construct a scaffold, which is a support system erected outside of buildings and structures being built. The scaffolding allows workers to access the upper levels of a building or structure safely by climbing these temporary structures and standing on platforms
Producction process
| Product Name | Scaffold Pipe | ||
| Grade | Q195, Q235 SGCC, SGCH,SGC340 SGC400 SGC440 SGC490 SGC570 SGHC SGH340 SGH400 SGH440 SGH490 SGH540 DX51D DX52D DX53D DX54D S220GD S250GD S280GD S320GD S350GD S400GD S500GD S550GD | ||
| Standard | API, ASTM, BS, DIN, GB, ASTM A53-2007,BS 1387,EN1219 GB/T3091-2001, BS1387-1985, DIN EN10025, EN10219, JIS G3444:2004, ASTM A53SCH40/80/STD. | ||
| Certification | API BIS BV ISO | ||
| W.T | 1.2-20mm | ||
| Length | Standard length is 5.8m 6m and 12m,we can cut length as customer request | ||
| Process | Threaded ,Coupling ,Groove | ||
| Application | 1. Fence, greenhouse, door pipe,greenhouse 2. Low pressure liquid, water, gas, oil, line pipe 3. For both indoor and outdoor the building construction 4. Widely used in scaffolding construction which is much cheaper and convenient | ||
| Zinc Coating | Pre Galvanized Pipe : 40g/m² ~275g/m² two side ; Hot Dipped Galvanized Pipe : 210g/m² ~560g/m² | ||
| Payment | 30% despoit in advance,70% after recepit of B/L copy.100% L/C is available. | ||
| Delivery | 15-30 days after despoit. | ||
| Advantages | 1.Reasonable price with excellent quality2.Abundant stock and prompt delivery 3.Rich supply and export experience, sincere service 4.Reliable forwarder, 2-hour away from por | ||
Packaging | Loose package; Packaged in bundles(2Ton Max); bundled pipes with two slings at the both end for easy loading and discharging; wooden cases; waterproof woven bag. | ||
| Out Diameter | Pre galvanized:1/2''-4''(21.3-114.3mm). Such as 38.1mm, 42.3mm, 48.3mm, 48.6mm or as customer request. | ||
| Hot dipped galvanized:1/2''-24''(21.3mm-600mm). Such as 21.3mm, 33.4mm, 42.3mm, 48.3mm, 114.3mm or as customer request. | |||
| Thickness | Pre galvanized:0.6-2.5mm. Hot dipped galvanized: 0.8- 25mm. | ||
| Technique | SSAW/LSAW/ERW Welded | ||
| Packing | 1.Big OD:in bulk 2.Small OD:packed by steel strips 3.woven cloth with 7 slats 4.according to the requirements of customers | ||
| Commodity | Pre Galvanized Square and Rectangular Steel Pipe |
| Outer Diameter | Square: 20*20mm~100*100mm Rectangular: 20*40mm~50*150mm |
| Thickness | 0.8~2.75mm |
| Length | Normal 5.8m, 6m ,random length can be customized |
| Zinc Coating | 40~275g/ |
| Tolerance | OD:+/-0.5mm |
| WT: +/-0.05mm | |
| Length: +/-20mm | |
| Straightness | As Per Standard |
| Material | Q195,Q215,Q235,Q355, Gr.A, Gr.B, S235-JRH,S275JRH, S355JRH STK400,STK500 |
| Standard | GB/T6728-2016 ,EN10219, ASTM A500, EN10305, AS1163 |
| Certificate | ISO 9001,IS014001,ISO45001,ISO50001,EN10219,LR,ICC,SGS.BV etc |
| Surface Treatment | Zinc coating ,Passivation, Marking, Embossing |
| Pipe End | Plain end / Blunt end / Screwed and socked & protected by plastic caps |
| Products Advantage | We select good quality coiling starting with raw material through mechanics, physics and chemistry experiments by our own laboratory. |
| The passivating liquid is in high grade, up to 16000, not mixed with water. | |
| Anti-rust in long time even used high temperature, wet and hot environment | |
| welding, bending, flattening and other deep processing are allowed | |
| Deep Processing Services | Threaded,sockets,end cap,painting,powder coated, oiled, punching,shrink,woven bag, stamping,embossing ect. |
| Packing | In Bundles, Water Proof Plastic Packing ,in Bulk etc |
| In hexagonal seaworthy bundles packed by steel strips. | |
| Small sizes nested into big sizes. | |
| Applications | Steel Structure,Scaffolding,Fence,Conduit,Greenhouse,Decorative pipe, Post, Roofing |
| Technical | ERW (high - frequency welded) |
| Trade Term | ERW,FOB, CFR, CIF, FCA, CPT, CIP |
| MOQ | Marketing(normal) Size: 1 MOQ OEM Size: 10 tons for each size |
| Shipment | 20 feet container , the max length 5.85m without coupling, 5.8m with coupling |
| 40 feet container , the max length 12.0m or 6.0m in two rows. | |
| Bulk carrier no limits on pipe length. |
| Chemical Composition | Mechanical Properties | |||||||
| C | Mn | Si | S | P | Yield | Tensile | Elongati | |
| Strength Mpa | Strenth Mpa | -on % | ||||||
| Q195 | 0.06-0.12 | 0.25-0.50 | ≤0.30 | ≤0.045 | ≤0.05 | ≥195 | 315-430 | ≥33 |
| Q215 | 0.09-0.15 | 0.25-0.55 | ≤0.30 | ≤0.05 | ≤0.045 | ≥217 | 335-450 | ≥27 |
| Q235 | 0.12-0.20 | 0.30-0.67 | ≤0.30 | ≤0.045 | ≤0.04 | ≥235 | 375-500 | ≥26 |
| Q345 | ≤0.20 | 1.00-1.60 | ≤0.55 | ≤0.04 | ≤0.04 | ≥345 | 470-630 | ≥22 |
Application
