Basic Info.
Product Description
Product Introduction
| 1000 Series | Industrial Pure Aluminum(1050,1060 ,1070, 1100) |
| 2000 Series | Aluminum-copper alloys(2024(2A12), LY12, LY11, 2A11, 2A14(LD10), 2017, 2A17) |
| 3000 Series | Aluminum-manganese alloys(3A21, 3003, 3103, 3004, 3005, 3105) |
| 4000 Series | Al-Si alloys(4A03, 4A11, 4A13, 4A17, 4004, 4032, 4043, 4043A, 4047, 4047A) |
| 5000 Series | Al-Mg alloys(5052, 5083, 5754, 5005, 5086,5182) |
| 6000 Series | Aluminum Magnesium Silicon Alloys(6063, 6061, 6060, 6351, 6070, 6181, 6082, 6A02) |
| 7000 Series | Aluminum, Zinc, Magnesium and Copper Alloys(7075, 7A04, 7A09, 7A52, 7A05) |
Specifications | Aluminum Pipe | ||
| Specifcation For Round Pipe | OD | 15nm-160nm |
| WT | 1-40mm | |
| Length | 1-12m | |
| Specification For Square Pipe | SIZE | 7X7mmm- 150X150 nlm |
| WT | 1-40mm | |
| Length | 1-12m | |
| Application | 1) Kitchenware, food and chemical products processing and storage devices; | |
| 2) Aircraft fuel tanks, oil pipe, rivets, wire; | ||
| 3) Cans cover, car body panels, steering plates, stiffeners, brackets and other components; | ||
| 4) Manufacturing trucks, tower building, ship, train, furniture, machinery parts, precision machining with the tubes, rods, shaped, sheet metal. | ||
| Grade | 6063 t5 ; 6061 t6 |
| Diameter | contact us for out/inside dia. |
| Length | 3000mm, or custom made |
| Process | Extrusion, Smooth Surface. |
| Service | Cutting, Anodizing, Custom-made. |
| Package | Export wooden pallets/cases |
| Mechanical Property | ||||||||
| ALUMINUM ALLOY | Grade | Normal Temper | Temper | Tensile Strength N/mm² | Yield Strength N/mm² | Elongation% | Brinell Hardness HB | |
| Plate | Bar | |||||||
| 1XXX | 1050 | O,H112,H | O | 78 | 34 | 40 | - | 20 |
| 1060 | O,H112,H | O | 70 | 30 | 43 | - | 19 | |
| Al-Cu (2XXX) | 2019 | O,T3,T4,T6,T8 | T851 | 450 | 350 | 10 | - | - |
| 2024 | O,T4 | T4 | 470 | 325 | 20 | 17 | 120 | |
| Al-Mn (3XXX) | 3003 | O,H112,H | O | 110 | 40 | 30 | 37 | 28 |
| 3004 | O,H112,H | O | 180 | 70 | 20 | 22 | 45 | |
| Al-Si (4XXX) | 4032 | O,T6,T62 | T6 | 380 | 315 | - | 9 | 120 |
| Al-Mg (5XXX) | 5052 | O,H112,H | H34 | 260 | 215 | 10 | 12 | 68 |
| 5083 | O,H112,H | O | 290 | 145 | - | 20 | - | |
| Al-Mg-Si (6XXX) | 6061 | O,T4,T6,T8 | T6 | 310 | 275 | 12 | 15 | 95 |
| 6063 | O,T1,T5,T6,T8 | T5 | 185 | 145 | 12 | - | 60 | |
| Al-Zn-Mg (7XXX) | 7003 | T5 | T5 | 315 | 255 | 15 | - | 85 |
| 7075 | O,T6 | T6 | 570 | 505 | 11 | 9 | 150 | |
Shandong Xuanlin Metal Materials Co., Ltd., was founded in 2008, covers an area of 10, 000 square metres. We are a professional manufacturing and trading company of metal building materials. We currently sell domestically and export worldwide to places such as Africa, North America and the Middle East. Our main products are aluminum foil, electrical cable, copper tube, boiler tube, casing pipe, honed tube, steel wires, PPGI/gi coil, galvanized pipe, steel structures. We have more than 30 production lines which can produce customize according to your requirements.
We ensure product quality through systematic testing with technically advanced equipment. Our company has a rang of well established long-term relationships with many domestic steel companies including Bao Steel Group, Hengyang Group, Yieh Phui(China) and Ma Steel Trading. Our advantage is that we are close to national highways and high speeds, 100 kilometers from Jinan Airport and 350 kilometers Tianjin Port...The benefits of light weight, low cost, high corrosion resistance and easy installation with short construction periods have LED to steel structures becoming more widly used in modern building construction with varied applications such as factory workshops, supermarkets, cold storage rooms, plazas, villas and more.
We look forward to building successful business relationships with customers around the world.
Q. Are you a factory or a pure trading company?
A: We are a factory.
A: for the same quality, our price is lower, for the same price, our quality is the best better.
Q. What are your company's strengths?
A: Factory spot, competitive prices, excellent quality, support factory inspection, video call at any time, technical support in 24/7. Simultaneously, we have participated in many international projects.
Q. Whether to support OEM or ODM?
A: We welcome customers to cooperate with us by OEM or ODM. We have a professional technical team, can be customized according to drawings or requirements.
Q. What trade terms do you usually use?
A: We use FOB, CIF, C&R, DDU, DDP.
Q. What is your usual delivery time?
A: From the execution date of the PI, spot products will be delivered within 3 days, and customized products within 15 days. Special circumstances, please communicate again. All our products have strict quality inspection before they leave the factory, to ensure that you receive the goods with excellent quality.
Q. What are your terms of payment?
A: We use TT and LC, or any other payment method available.
